Connectivity2G only: GSM/GPRS quad-band with Bluetooth 4.0 LE. UK 2G switch-off is scheduled from 2029 (EE, O2) into 2030 (Vodafone).
InstallationHardwired with a 5-pin cable: 10-30 V power, ground, ignition and two outputs, with a 3 A external fuse. Professional fitting recommended.
ProtectionIP67 case, dust-tight and protected against immersion, with internal GNSS and GSM antennas.
Power and battery10-30 V DC input (12 V nominal) with a 1200 mAh Li-ion backup battery. Power-off sleep draws under 1 mA.
GNSSGPS, GLONASS, Galileo, BeiDou, SBAS and QZSS, position accuracy under 2.5 m CEP.
Inputs/outputs1 digital input for ignition and 2 open-drain digital outputs to drive a relay or immobiliser (relay not included).
AlertsTowing, unplug and jamming detection, auto and manual geofences, crash detection and eco driving.
Dimensions79 x 43 x 22 mm (89 mm with the connector), 74 g.
Use casesMotorbikes, quads, boats and jet skis (tracking, not navigation) and trailers wired to 12/24 V.
Unlocked useSold without a SIM card and not locked to Fleetalyse. Use your own compatible IoT/M2M SIM card, APN and telematics platform configuration.
