ConnectivityEU version of the 4G LTE Cat 1 radio, covering the main UK bands, with 2G GSM fallback. No Bluetooth.
InstallationBattery-mounted: tape on the back and two wires to the battery terminals. Ignition comes from battery voltage and movement.
ProtectionIP69K casing, sealed against dust, high-pressure water jets and steam cleaning.
Power and battery10-30 V DC (12 V nominal) with a 320 mAh Li-ion backup battery; Power Off Sleep under 0.601 mA at 12 V.
GNSSGPS, GLONASS, Galileo and BeiDou on a 75-channel L1 receiver, up to 41 satellites in view, < 1.8 m CEP.
Inputs/outputsNone. Power and ground only, so no immobiliser, no CAN and no Bluetooth sensors. Nano-SIM, USB Type-C.
Driving and crashCrash detection with optional crash trace, eco driving, over-speeding, idling, trips and odometer, towing, unplug and jamming alerts.
Dimensions118 x 48 x 18.5 mm, 118 g. Rated 0 °C to +40 °C with the backup battery fitted.
Use casesVans and cars, plant and machinery with a 12/24 V battery, driver behaviour and insurance telematics.
Unlocked useSold without a SIM card and not locked to Fleetalyse. Use your own compatible IoT/M2M SIM card, APN and telematics platform configuration.
