Connectivity4G LTE Cat 1 (B1/B3/B5/B7/B8/B20/B28) with 2G GSM fallback, GNSS and Bluetooth 5.3 LE.
InstallationBattery-mounted: pre-applied double-sided tape and two wires straight to the battery terminals. Ignition is detected from battery voltage and movement, so there is no ignition wire.
ProtectionIP69K casing, sealed against dust, high-pressure water jets and steam cleaning.
Dead reckoningBuilt-in accelerometer and gyroscope keep the route going through tunnels, car parks and built-up areas when the GPS signal drops.
Crash detection400 Hz accelerometer with configurable crash trace recording and crash severity data.
GNSSGPS, GLONASS, GALILEO and BEIDOU, 75-channel L1 receiver, <1.8 m CEP position accuracy.
Power and battery10-30 V DC input (12 V nominal) with a 320 mAh Li-Ion backup battery and unplug detection.
Dimensions118 x 48 x 18.5 mm, 118 g, internal high-gain GNSS and GSM antennas, 128 MB memory.
Use casesInsurance telematics, cars and vans, plant and machinery, rental and leasing fleets.
Unlocked useSold without a SIM card and not locked to Fleetalyse. Use your own compatible IoT/M2M SIM card, APN and telematics platform configuration.
